6ES7193-6BP20-0DA0 Siemens ET200SP Base Unit BU15 A0
Product Introduction
The Siemens 6ES7193-6BP20-0DA0 is a BU15‑P16+A10+2D base unit (BU type A0) for the SIMATIC ET200SP distributed I/O system. It provides reliable mechanical mounting and electrical connection for standard ET200SP I/O modules, featuring 16 process terminals + 10 auxiliary (AUX) terminals and tool‑free push‑in connection.
Key Features
- Model: 6ES7193-6BP20-0DA0 (BU15‑P16+A10+2D)
- Type: A0 base unit, 15 mm slim width, height 141 mm
- Terminals: 16 push‑in process terminals + 10 AUX terminals
- New load group (no potential continuation from left)
- Hot‑swap capable for module replacement during operation
- IP20 protection, CE/RoHS compliant, industrial grade
Technical Specifications
- Dimensions: 15 mm × 141 mm × 35 mm (W×H×D)
- Supply Voltage: 24 V DC
- Current Capacity: P1/P2 bus max 10 A; AUX bus max 10 A; per channel 2 A
- Operating Temperature: -30 °C to +60 °C (horizontal); -30 °C to +50 °C (vertical)
- Mounting: 35 mm DIN rail, vertical installation
- Compatibility: All ET200SP A0‑type I/O modules (digital/analog/communication)
Applications
Widely used in machine tools, packaging lines, logistics systems, and process automation, especially where extra auxiliary terminals and new load group isolation are required. The A0 type is ideal for digital I/O, communication, and basic analog modules.
Our Advantages
- 100% original Siemens, factory new and sealed
- Competitive pricing for 6ES7193 series base units
- Fast global delivery via DHL/FedEx/UPS
- Professional technical support & after‑sales service
