6ES7151-8AB01-0AB0 Siemens ET200S IM151-8 PN/DP CPU 192KB Germany
Product Introduction
6ES7151-8AB01-0AB0 is the IM151-8 PN/DP CPU module of the original Siemens SIMATIC ET200S distributed I/O system from Germany. It integrates PROFINET (3-port RJ45)+optional PROFIBUS DP dual communication, 192KB working memory, no battery design, and requires MMC memory card. It is the core unit for small and medium-sized distributed control.
Key Features
Model: 6ES7151-8AB01-0AB0 (IM151-8 PN/DP CPU)
Origin: Germany (original from Germany)
Memory: 192KB working memory, 64KB holding memory, maximum 8MB MMC
Communication: 3 x RJ45 PROFINET (100Mbps, IRT real-time); Scalable PROFIBUS DP master station
Control capability: IO controller, up to 128 I/O devices, expandable to 63 ET200S modules
Design: No battery, relying on MMC to store programs/data; Hardware V01, firmware V3.2
Size: 120mm x 119.5mm x 75mm (width x height x depth)
Protection: IP20, CE/RoHS/UL certified, industrial grade
Programming: TIA Portal/STEP 7, supports LAD/FBD/SCL/STL
Technical Specifications
Power supply: 24V DC (20.4-28.8V), reverse polarity protection, typical power consumption 5.5W
Current: Input maximum 1.8A; Backplane bus 5V/700mA
Temperature: -25 ° C~+60 ° C (operating); -40 ° C~+70 ° C (storage)
Weight: Approximately 387g; 35mm DIN rail installation
Performance: Bit instruction 0.06 μ s, floating point 0.59 μ s; PROFINET IRT cycle 125 μ s
Applications
Suitable for machine tools, packaging machinery, logistics, and process automation, especially suitable for:
ET200S station independent CPU control, no need for central PLC, on-site intelligent control
PROFINET+PROFIBUS hybrid network, compatible with both old and new systems
High speed motion control (servo synchronization, high-speed sorting) requires IRT real-time communication
Compact control cabinet with nearby installation of control units to reduce wiring costs
Our Advantages
100% German original, brand new and unopened, genuine product guarantee
ET200S full range of spot goods, batch price advantage
Global Fast Shipping (DHL/FedEx/UPS)
Professional technical support and after-sales service (2-year warranty)
