New Original Siemens 6ES7505-0RB00-0AB0 PS60W HF Power Module 24/48/60VDC For S7-1500 PLC Backplane Power Supply
We supply brand new original sealed Siemens 6ES7505-0RB00-0AB0 PS60W HF high-frequency system power module, exclusive for SIMATIC S7-1500 main rack backplane bus power feeding.
Core Technical Specs
- Multi-range DC input: 24VDC/48VDC/60VDC universal input; Rated 60W 5V backplane bus output to supply CPU, I/O and communication modules.
- Built-in 20ms power failure buffer function, capacitor energy storage without backup battery, protects CPU retain data during momentary power drop.
- Full protection: reverse polarity, overload, short-circuit, overvoltage protection; RUN/ERROR/MAINT LED status indicator, TIA Portal online diagnostic available.
- Size:105(W)×147(H)×129(D)mm, standard 35mm DIN rail mounted on left side of S7-1500 CPU, IP20, working temp -20℃~+60℃.
