Sales Brand New Original Siemens 6ES7545-5DA00-0AB0 CM PROFIBUS DP Communication Module for ET200SP S7-1500 PLC
We supply brand new original sealed Siemens 6ES7545-5DA00-0AB0 CM PROFIBUS DP communication module, specially designed for ET200SP CPU 1510SP-1 PN & 1512SP-1 PN under SIMATIC S7-1500 system, expanding extra PROFIBUS DP communication port for PLC control system.
Core Technical Parameters
- Interface: 9-pole D-Sub female socket, RS485 electrical PROFIBUS DP port
- Baud rate: 9.6kbps ~ max 12Mbps auto-adaptive, max cable length 100m at 12Mbps
- Working voltage: DC 19.2~28.8V (24VDC standard), powered by PLC backplane bus
- Communication mode: Support PROFIBUS DP Master (connect up to 125 DP slaves) & DP Slave, S7 communication, PG/OP online debugging
- Data buffer: 244Byte input & 244Byte output cache, max 128Byte user I/O data per address area
- Dimension: 147×35×129mm, IP20 protection, DIN rail mounting, operating temp:0~+60℃
- Cert: CE, UL, cULus, RoHS certified
