Original Germany Siemens 6ES7516-3AN02-0AB0 CPU1516-3 PN DP S7-1500 PLC With 2×PROFINET + 1×PROFIBUS DP Onboard
Original factory-sealed Siemens 6ES7516-3AN02-0AB0 (CPU 1516-3 PN DP), upper-middle performance main CPU of S7-1500 series, imported from Germany, designed for large centralized automation control.
Core Technical Specifications
- Working Memory: Program 1500KB, Data 1000KB; SIMATIC memory card required for program backup, firmware update and mass data logging
- Built-in Interfaces: 2 independent PROFINET RJ45 ports + 1 integrated PROFIBUS DP (9Pin D-Sub) interface; Support PROFINET IO Controller/Device, PROFIBUS DP Master/Slave, S7 communication, TCP/IP, ISO-on-TCP, Modbus TCP
- Running Performance: Binary instruction execution around 10ns, supports complex PID regulation, multi-axis motion control and multi-station networking
- Expandability: Match full series S7-1500 DI/DO/AI/AO/CM/CP modules via backplane rack
- Environment: IP20 protection, DIN rail installation, working temperature 0℃~+60℃
