Spot Original Germany Siemens 6DD1607-0AA1 FM458-1 DP Technology Application Module For SIMATIC S7-400 High Precision Motion Control PLC
Complete order number: 6DD1607-0AA1
Product Model: FM458-1 DP Process Application Controller Module
Adaptation platform: Siemens SIMATIC S7-400 PLC automation system, 6DD series high-end motion control core main control board
Origin: Made in Germany
Core hardware configuration
Processor: 64 bit RISC high-speed computing CPU, with a minimum control cycle of up to 0.1ms
Built in memory: 16MB DRAM+64MB SDRAM+512KB SRAM
Communication interface: 1 PROFIBUS-DP (RS485) main station interface (up to 12Mbps), 1 V.24 (RS232) debugging serial port, 1 X2 high-speed digital trigger input port
Power supply specifications: Backboard 5VDC, rated working current 2.3A, S7-400 standard single slot rack installation
Core functions: Independently execute high-precision closed-loop control, multi axis synchronous motion, tension/pressure/position process algorithms, and can independently perform high-speed calculations without the S7-400 main CPU, greatly reducing the load on the main CPU; Can be paired with EXM438/EXM448 series expansion modules to expand high-speed IO and multi device synchronous communication capabilities
Programming language: Supports CFC and SFC process control programming languages, compatible with TDC high-end control configuration logic
Working temperature range: 0 ℃~+60 ℃ Industrial wide temperature range, IP20 protection, strong EMC anti electromagnetic interference
Source status: Brand new factory sealed stock, 12-month warranty, supports global bulk foreign trade supply
