Agent Supply Original Germany Siemens 6ES7461-0AA00-0AA0 IM461-0 Receiver Interface Module For S7-400 Centralized Rack Expansion
Complete order number: 6ES7461-0AA00-0AA0
Product Model: IM 461-0 Centralized Extended Receiver Interface Module (with K-Bus)
Compatible System: Siemens SIMATIC S7-400 PLC, must be used in conjunction with the main rack IM460-0 (6ES7460-0AA01-0AB0) and the sending module
Origin: Genuine Import from Germany (Made in Germany)
Bus Support: Simultaneous transmission of P process bus + K communication bus, capable of transmitting process IO mapping, S7 global data, and PLC-to-PLC communication data
Accessory dedicated cable: 6ES7468-1BF00-0AA0, maximum transmission distance 5 meters (fixed, not extendable)
Expansion capability: A single IM461-0 module can connect up to 4 expansion racks in series; a single CPU can support a maximum of 2 IM460-0 modules, with the entire system capable of expanding up to 8 ER expansion racks
Electrical Parameters: Powered by a 5VDC backplane, with a maximum operating current of 290mA and a power consumption of 1.45W. No additional 24V power module is required for the rack expansion; power is supplied via the main rack bus
Hardware specifications: S7-400 single slot installation, dimensions 25mm×290mm×220mm, net weight approximately 250g
Operating temperature range: 0°C to +60°C (rack-mounted), IP20 protection, industrial EMC anti-interference design
Status indicator lights: INTF (rack address setting fault), EXTF (bus link communication fault) dual-channel fault diagnosis indicator lights
Supply Status: Siemens Authorized Agency Channel, Brand New Factory-Sealed Stock, 12-Month Warranty, Supports Global Bulk Foreign Trade Supply
