New Original Germany Siemens 6ES7460-3AA01-0AB0 IM460-3 Transmitter Interface Module For S7-400 Distributed Rack Expansion Up To 102M With K-Bus
Complete order number: 6ES7460-3AA01-0AB0 (you abbreviated as 6ES7460-3AA0-0AB0, the standard model suffix is 3AA01)
Product Model: IM 460-3 Distributed Expansion Send Interface Module
Adaptation system: Siemens SIMATIC S7-400 PLC main rack, must be used in pairs with the IM461-3 (6ES7461-3AA01-0AA0) receiving module
Origin: Genuine German Import (Made in Germany)
Maximum transmission distance: 102 meters, suitable for distributed IO deployment of multiple control cabinets in medium to short distances within factory premises
Bus Support: Supports both the P process bus and the K (C) communication bus simultaneously, enabling the transmission of I/O process image data as well as cross-rack global data and high-speed communication between multiple CPUs. It is the IM460 model that balances both distance and cross-rack communication among the four variants
Expansion Capability: Each single module features a 2-way expansion interface, with a maximum of 4 expansion racks cascaded per link. A single IM460-3 module can drive up to 8 remote ER expansion racks. A single S7-400 CPU can be configured with up to 6 IM460-3 modules, supporting a maximum of 21 expansion racks in the entire system
Electrical Parameters: The main rack backplane is powered by 5VDC, with a maximum operating current of 1550mA and a total power consumption of 7.75W. All remote expansion racks must be independently configured with PS407 power modules for separate power supply and cannot draw power from the main rack bus
Hardware Configuration: Dual-channel dedicated expansion bus interface, equipped with two status diagnostic indicators for INTF (internal configuration fault) and EXTF (external bus fault); accompanied by Siemens dedicated expansion cables of the 6ES7468 series
Physical specifications: Single-slot S7-400 UR rack-mounted, dimensions 25mm × 290mm × 280mm, net weight 630g
Working environment: 0°C to +60°C for rack operating temperature, IP20 protection, compliant with industrial EMC anti-interference standards
Supply Status: Brand new, factory-sealed, ready stock with 12-month warranty, supporting global bulk export supply
