Sales Original Germany Siemens 6ES7400-0HR50-4AB0 S7-400H Full Redundant System Bundle CPU412-3H 24/48/60VDC UR2-H Rack
Complete order number: 6ES7400-0HR50-4AB0
Product Name: SIMATIC S7-400H CP412-3H Complete High Availability Redundant System Kit (DC Wide Voltage Edition)
Origin: Made in Germany
Firmware version: V4.5, compatible with short-range multi-mode fiber optic synchronization architecture, dedicated for redundant deployment in the same cabinet
Standard List of Package Standards
1 set of UR2-H dual redundant rack (2 × 9 slots), supporting parallel redundant installation of dual CPUs
2 PS405 10A redundant power modules, input voltage DC24/48/60V wide voltage
2 CPUs 412-3H redundant central processing units, working memory 1MB (program 512KB+data 512KB)
4 pieces of 6ES7960-1AA04-0XA0 10 meter short distance multimode fiber optic synchronization module
2 6ES7960-1AA04-5AA0 1-meter LC duplex cross synchronous optical fibers
4 spare lithium buffer batteries for S7-400 CPU
Basic performance parameters of CPU
Boolean instruction processing time: 100ns, supports small and medium-sized process logic operations, and interlock protection control
Maximum process IO: 131072 DI/DO, 8192 AI/AO
Integration: MPI+independent PROFIBUS DP dual master interface, supporting ET200M redundant remote IO networking
Support CiR online hardware modification, IO module hot plugging, and microsecond level fault-tolerant redundancy switching
Electrical environmental parameters
Working temperature: 0 ℃~+60 ℃ (horizontal rack installation), IP20 protection level
Compatible programming software: STEP7 V5.4 and above, PCS7 process control system
Note: The kit does not include the S7-400 dedicated RAM memory card and requires separate selection
Source status: Brand new factory sealed stock, 12-month warranty, supports global bulk supply of spare parts for foreign trade
