Agent Supply Original Siemens 6ES7400-0HR00-4AB0 S7-400H Complete Redundant PLC System Bundle CPU412-3H 120/230VAC UR2-H Rack
Complete order number: 6ES7400-0HR00-4AB0
Product Name: SIMATIC S7-400H CP412-3H High Availability Redundant System Kit (AC Power Supply Edition)
Firmware version: V4.5, compatible with 6ES7960-1AA04 series 10 meter short distance multimode fiber optic synchronization module
Origin: Made in Germany
1、 Official standard configuration details of the kit
1 set of UR2-H dual redundant dedicated 9-slot rack (dual bus design, used for parallel redundant installation of dual CPUs)
2 PS407 10A AC power modules, input voltage: AC 120/230V mains power supply
2 CPUs 412-3H redundant central processing units, working memory 1MB (program 512KB+data 512KB)
4 pieces of 6ES7960-1AA04-0XA0 multimode fiber optic synchronization submodule (maximum transmission distance 10 meters)
2 6ES7960-1AA04-5AA0 1-meter LC duplex cross type synchronous optical fibers
4 spare buffer lithium batteries dedicated to S7-400 CPU
Note: The kit does not include S7-400 RAM/EEPROM memory card and needs to be purchased separately from Siemens Industrial ..
2、 CPU core performance parameters
Boolean instruction execution time: 100ns, suitable for small and medium-sized process chain and protection logic control
Maximum process IO addressing: 131072 DI/DO, 8192 AI/AO
Integrated interface: 1 MPI/DP multiplexed interface+1 independent PROFIBUS DP master interface, supporting ET200M redundant remote IO networking
Redundancy features: hardware level microsecond level undisturbed switching, support CiR online hardware configuration modification, IO module hot plugging
Software compatibility: STEP7 V5.4 and above, PCS7 process control system
3、 Environmental electrical parameters
Protection level: IP20, DIN standard rack installation
Working temperature: Horizontal rack 0 ℃~+60 ℃, storage temperature -40 ℃~+85 ℃
Power input: AC 120/230V wide voltage industrial mains power
Source status: Siemens authorized agent for brand new factory sealed stock, 12-month warranty, supports global bulk ordering for foreign trade
