Original Germany Siemens 6ES7417-4XT05-0AB0 SIMATIC S7-400 CPU 417-4 PLC Controller 30MB Memory Firmware V5.3
Order model: 6ES7417-4XT05-0AB0
Product Name: SIMATIC S7-400 CPU 417-4 Central Processing Unit (Standard Single Machine Non Redundant Type)
Origin: Imported from Germany with original packaging
Firmware version: V5.3
Working memory: 30MB (15MB for program storage and 15MB for data storage), supports up to 64MB S7-400 dedicated RAM/EPROM memory card expansion Industry M
Computational performance
Boolean instruction: typical 18ns
Fixed point operation: 18ns
Floating point operation: 54ns, suitable for large DCS complex process algorithms, massive data interaction, multi device chain control Quick Time
Integrated communication interface
Interface 1: MPI/PROFIBUS DP multiplex interface, up to 12Mbps, supports PG programming, HMI, S7 bilateral communication, DP master/slave station
Interface 2: Independent PROFIBUS DP master interface, capable of mounting ET200M distributed remote IO stations
Dual IFM expansion slot: can expand 2 IF964-DP communication submodules, up to four PROFIBUS DP bus networking starcontro
IO process addressing capability
Maximum digital quantity: 131072 DI/131072 DO
Maximum Analog Quantity: 8192 AI/8192 AO
Default process image area: 1024 byte input+1024 byte output, maximum consistent transmission length of 244 bytes
Up to 21 racks can be expanded, supporting IM460 series remote expansion, with a maximum of 44 S7 communication connections
Electrical and Environmental Parameters
Power supply: S7-400 rack backplane DC5V power supply, typical working current 1.3A, maximum 1.6A
Protection level: IP20, standard UR rack DIN rail installation
Working temperature: Horizontal installation 0 ℃~+60 ℃; Storage temperature -40 ℃~+85 ℃
Core functions: Supports CiR online hardware configuration modification, ET200M IO module hot plugging, isochronous mode, multi priority interrupt, time interrupt, process alarm, S7 routing function
Software requirements: STEP7 V5.3 SP2 and above versions, perfectly compatible with PCS7 process control system starcontro
Note: Excluding S7-400 dedicated memory card, it needs to be purchased separately
Product lifecycle: The original factory has ceased production and is mainly used for replacing spare parts for old and large S7-400 DCS projects
Source: Brand new original German stock, 12-month warranty, supports global bulk foreign trade supply
