Spot Original Germany Siemens 6ES7416-3XR05-0AB0 SIMATIC S7-400 CPU 416-3 PLC Controller 11.2MB Memory Dual PROFIBUS DP Interfaces Firmware V5.3
Complete order number: 6ES7416-3XR05-0AB0
Product model: SIMATIC S7-400 CPU 416-3 (dual PROFIBUS DP interface, no integrated PROFINET Ethernet, single machine non redundant CPU)
Origin: Imported from Germany with original packaging
Firmware version: V5.3
Working memory: 11.2MB (program storage 5.6MB+data storage 5.6MB), maximum expandable 64MB S7-400 dedicated RAM/EPROM memory card 4ind-hub.s
Computational performance: Boolean instruction execution time of 30ns, floating-point operation of 90ns, suitable for large DCS systems, complex process algorithms, massive remote IO centralized control, multi area distributed DP bus networking
Power supply method: S7-400 UR rack backplane DC5V power supply, typical working current 1.2A, maximum 1.4A
Protection level: IP20, DIN standard rail rack installation
Working temperature: Horizontal installation 0 ℃~+60 ℃, storage temperature -40 ℃~+85 ℃
Core functions: Supports CiR online hardware configuration modification, ET200M IO module hot plugging, PROFIBUS synchronous mode, multi priority interrupt, S7 routing, process alarm diagnosis, etc
Software adaptation: Minimum requirement STEP7 V5.3 SP2 and installation of corresponding hardware update package, perfectly compatible with PCS7 process control system
Note: Excluding S7-400 dedicated memory card, Siemens original memory card needs to be separately selected
Product status: The original factory has ceased production and is mainly used for replacing spare parts in old PROFIBUS bus type large-scale DCS projects
Source status: Brand new factory sealed stock, 12-month warranty, supports global bulk supply for foreign trade
