Brand New 6ES7 332-7ND02-0AB0 SIMATIC SM332 Channel Isolation Analog Output Expansion Module 20Pin Connector
New Original Siemens 6ES7332-7ND02-0AB0 SM332 analog output module for SIMATIC S7-300 PLC, 4 independent galvanic isolated AO channels, 16-bit high resolution, multi-range output: 0-10V/1-5V/±10V voltage, 0/4-20mA/±20mA current, support isochronous synchronization, DC24V power with reverse polarity & short-circuit protection, 20-pin front connector, widely used for inverter, regulating valve, hydraulic proportional control in chemical, water treatment, machinery industry。
Part No：6ES7332-7ND02-0AB0
Series：SIMATIC S7-300
Type：SM332 Analog Output（AO）
Channels: 4 AO, channel isolation
Resolution: 16-bit (including sign bit)
Voltage Output: 0–10 V, ±10 V, 1–5 V
Current Output: 0/4–20 mA, ±20 mA
Isolation：Channel-to-channel galvanic isolation
Conversion Time: 200 μs/channel; Isochronous Mode 640 μs
Connector：20-pin front connector
Power Supply: 24 V DC (Load) + Backplane 5 V DC
Dimension (W×H×D)：151×131×52 mm
Weight：≈0.296 kg
Origin：Germany
Status：Brand New Original
Warranty：12 months
✅ Channel isolation: Each channel is independently electrically isolated, with strong anti-interference ability, protecting the backplane bus.
✅ 16 bit high precision: With a resolution of up to 16 bits, the output signal is fine and suitable for precise control scenarios.
✅ Multi signal compatibility: covering mainstream voltage/current range, suitable for various industrial actuators.
✅ Isochronous mode optimization: Supports PROFIBUS DP isochronous mode, with shorter bus cycles and better real-time performance.
✅ Diagnostic protection: Supports channel level diagnosis (disconnection/short circuit), voltage output short circuit protection (≤ 40 mA).
