Proxy Original Siemens 6ES7216-2BD23-0XB8 CPU226 40I/O PLC Controller for S7-200 CN
As authorized proxy, we offer brand new original Siemens 6ES7216-2BD23-0XB8 (CPU226) compact PLC, the high-end controller for S7-200 CN series. Integrated 24-channel DC24V digital inputs and 16-channel relay outputs (40 I/O points total), expandable up to 248 digital I/O or 35 analog I/O with 7 extension modules. Built-in 13KB program/data memory, dual RS485 communication ports (PPI/MPI/Free-port), 6×30kHz high-speed counters and 2×20kHz high-speed pulse outputs. Factory sealed, CE certified, 12-month official warranty, global delivery and technical support available.
Part No: 6ES7216-2BD23-0XB8
Model: CPU226 (S7-200 CN)
Power Supply: AC 120/230V Digital
Input: 24×DC24V (sink/source)
Digital Output: 16×Relay (280mA/400mA per point)
Program Memory: 13KB Data
Memory: 10KB
Communication: 2×RS485 (PPI/MPI/Free-port)
High-speed Functions: 6×30kHz counters, 2×20kHz pulse outputs
Expansion: Max 7 modules (248 digital/35 analog I/O)
Working Temperature: 0℃ ~ +55℃
Protection Grade: IP20
