Supply Brand New Original Siemens 6ES7214-2AD23-0XB8 CPU224XP PLC S7-200 CN Controller
We supply brand new original Siemens 6ES7214-2AD23-0XB8 (CPU224XP CN) compact PLC, part of SIMATIC S7-200 CN series. This is a DC/DC/DC type (24VDC power, DC input & transistor output) with 14×DC24V digital inputs, 10×DC24V transistor outputs (0.75A/pt), plus 2 integrated analog inputs (AI) and 1 analog output (AO) for direct sensor/actuator connection without extra modules.
Equipped with 12KB standard / 16KB extended program memory, 10KB data memory, dual RS‑485 communication ports (PPI/MPI/Free‑port), 6×30kHz high‑speed counters, and 2×20kHz pulse outputs for precise motion control. Supports up to 7 expansion modules (digital/analog/communication). CE certified, factory sealed, 12‑month official warranty, global shipping and technical support available.
- Part No: 6ES7214-2AD23-0XB8
- Model: CPU224XP CN (S7-200 CN)
- Power Supply: DC 24V (21–28V wide voltage)
- Digital Input: 14×DC24V
- Digital Output: 10×DC24V Transistor (0.75A/pt)
- Analog Input: 2×(voltage/current selectable, 12-bit)
- Analog Output: 1×(voltage/current selectable, 12-bit)
- Program Memory: 12KB (std) / 16KB (ext)
- Data Memory: 10KB
- Communication: 2×RS‑485 (PPI/MPI/Free‑port)
- High‑speed Functions: 6×30kHz counters, 2×20kHz pulse outputs
- Expansion: Max 7 modules (168 digital/35 analog I/O)
- Working Temperature: 0°C ~ +55°C
- Protection Grade: IP20
- Dimensions (W×H×D): 140×80×62 mm
- Weight: ≈0.44 kg
