Siemens PLC module 6ES7214-1AD23-0XB8 CPU212 programmable module from Germany
Clarification: This is CPU224 CN (not CPU212), part of Siemens SIMATIC S7-200 CN series. We supply Germany-origin, brand-new original 6ES7214-1AD23-0XB8 compact PLC, with DC/DC/DC configuration (24VDC power, 24VDC input, transistor output). It has 14×DC24V digital inputs and 10×DC24V transistor outputs (0.75A/pt).
Equipped with 8KB standard / 12KB extended program memory, 8KB data memory, 1×RS‑485 communication port (PPI/MPI/Free‑port), 6×30kHz high‑speed counters, and 2×20kHz pulse outputs for motion control. Supports up to 7 expansion modules (max 168 digital I/O). CE certified, factory sealed, 12‑month warranty, global shipping & technical support.
Part No: 6ES7214-1AD23-0XB8
Model: CPU224 CN (S7-200 CN)
Power Supply: 24VDC (21–28V)
Digital Input: 14×DC24V
Digital Output: 10×DC24V Transistor (0.75A/pt)
Program Memory: 8KB (std) / 12KB (ext)
Data Memory: 8KB
Communication: 1×RS‑485 (PPI/MPI/Free‑port)
High‑speed Functions: 6×30kHz counters, 2×20kHz pulse outputs
Expansion: Max 7 modules (168 digital I/O)
Working Temperature: 0°C ~ +55°C
Protection Grade: IP20
Dimensions (W×H×D): 140×80×62 mm
Weight: ≈0.44 kg
Origin: Germany (Genuine Siemens)
