Sales of New Original Siemens 6ES7212-1BB23-0XB8 CPU222 PLC 8DI/6DO Relay Output Module
Note: This model is CPU222 (not CPU212), part of Siemens SIMATIC S7-200 CN series. We supply new original Siemens 6ES7212-1BB23-0XB8 compact micro PLC with DC/Relay configuration (24VDC power, 24VDC input, relay output). It has 8×DC24V digital inputs and 6×relay digital outputs (2A/pt, 250VAC/30VDC).
Equipped with 4KB program memory / 2KB data memory, 1×RS‑485 communication port (PPI/MPI/Free‑port), 4×30kHz high‑speed counters, and 2×20kHz high‑speed pulse outputs. Supports up to 2 expansion modules (max 78 digital I/O). Factory sealed, CE certified, 12‑month official warranty, global delivery & technical support.
Part No: 6ES7212-1BB23-0XB8
Model: CPU222 (S7-200 CN)
Power Supply: 24VDC (21–28V)
Digital Input: 8×DC24V (sink/source)
Digital Output: 6×Relay (2A/pt, 250VAC/30VDC)
Program Memory: 4KB
Data Memory: 2KB
Communication: 1×RS‑485 (PPI/MPI/Free‑port)
High‑speed Functions: 4×30kHz counters, 2×20kHz pulse outputs
Expansion: Max 2 modules (78 digital I/O)
Working Temperature: 0°C ~ +55°C
Protection Grade: IP20
Dimensions (W×H×D): 90×80×62 mm
Weight: ≈0.57 kg
